TLSD Camera Probe for Borehole Inspection Camera System

Availability:
Quantity:

Product Description


Description

The high-definition free of dead corner rotation camera is the latest developed product.

New ideas, new design, using two cameras to work at the same time; One camera is keep downward direction to observe the overview of the well; The other one is installed in the middle of the probe, outside of which placed circular glass cover, it is a ultra high-definition digital camera, could do 360 degree rotation scanning on the wall,  lighting and camera rotate synchronously.

Such design can realize watching the details of the wall more clearly . It has automatic focusing system; Equipped with a plane light source system with 1024 pieces of CBO , almost the same as natural light, more uniform, more realistic imaging. The imaging effect is 10 times or more higher than the ordinary underground TV camera.

TLSD Camera Probe for Borehole Inspection Camera System-2

TLSD Camera Probe for Borehole Inspection Camera System-3

TLSD Camera Probe for Borehole Inspection Camera System-4 TLSD Camera Probe for Borehole Inspection Camera System-5

TLSD Camera Probe for Borehole Inspection Camera System-6

Specifications
 Sn.  Item  Paramerter
1  Probe Size  Φ79 mm
2  Probe Material  Stainless steel
3  Camera Cover Material  High boron silicon toughened glass
4  Rotatable Angle  Two cameras: Wide angle & 360 °
5  Light  A plane light source system with 1024 pieces of CBO
6  Proof Pressure  5-15MPa
7  Focal Distance  Automatical
8  Brightness Level  5 levels adjustable
