TLSG Camera Probe for Borehole Inspection Camera System

Quantity:

Product Description

Description

The latest design camera probe. Compact structure, small volume and smart look etc., could not totally tell its advantages.

Rotate smoothly with two group of LED light, large area will be illuminated, the light is more uniform, what’s more, its brightness is adjustable in 5 grades; That means you could view the pictures of the wall of well more clearly.

Small size make it possible to be used in very narrow well, so it has a wider range of purposes and applications.

More specifications details found below
TLSG Camera Probe for Borehole Inspection Camera System-1

TLSG Camera Probe for Borehole Inspection Camera System-2

TLSG Camera Probe for Borehole Inspection Camera System-3

TLSG Camera Probe for Borehole Inspection Camera System-4

 Sn.  Item  Paramerter
1  Camera quality  700TVL CCD,HD low illumination level(extremely sensitive)
2  Probe material  304 stainless steel or anodized aluminum alloy hard shell
3  Camera cover  Explosion-proof optical acrylic glass or explosion-proof glass windows
4  Rotatable angle  One is wide angle, the other is 360 degree
5  LED Light quantity  8/12 pieces on the front;24 pieces on the behind
6  Brightness adjustable  Both of the front and behind LED lights,could be adjusted the brightness in 5 grades
7  Pressure proof  15MPa(equal to 1500 meter water pressure)
8  Probe size  Φ50/75mm
