TLSF Camera Probe for Borehole Inspection Camera System

Quantity:

Product Description


Description

This probe equipped with 4 pieces of HD cameras. One is on the end of the probe, keep the downward direction , and the other three cameras are on the middle of the probe, covering fan-shaped distribution.

By using this probe, we could inspect the well free of dead angle without any operating, and thanks to our OSD technology, four imaging can be viewed by one screen at the same time!

So it is very convenient to observe every detail of the well, you would not miss anything.

TLSF Camera Probe for Borehole Inspection Camera System-1

Specifications
 Sn.  Item  Paramerter
1  Sensor  1/3 inch CCD,Industrial-grade wide dynamic high speed
2  Resolution  1200TVL
3  Inspecting Angle  150°+120°+120°+120°
4  Signal system   PAL
5  Minimum illumination  0.001LUX/F1.2
6  White Balance Mode  AWB
7  Backlight compensation  HLC
8  Working voltage  DC12V±5%
9  Light  81 pieces of LED
10  Pressure proof  15MPa(equal to 1500 meter water pressure)
