Description
Probe size is available for Φ70 to 120mm, depands on the diameter of well; its material is stainless steel, it is strong and rust-proof, also, have high water pressure proof ability.
Front and Rear Lights design, make the inspection video much clearer.
Rotatable capacity: LR(circle) and UD(Bend forward), you can adjust any inspection angle you want.
A brightness control: can be adjusted by button on the main box front light source brightness, dimming level 5. It is very convenient and useful.
Specfications | Sn. | Item | Paramerter |
| 1 | Probe Size | Φ90 mm (70/75/100/120 available) |
| 2 | Probe Material | Stainless steel |
| 3 | Camera Cover Material | Explosion-proof optical glass |
| 4 | Camera Pixels | CCD720 HD (better than CMOS camera, 1200 line) |
| 5 | Rotatable Angle | LR 360 °, UD 180 ° |
| 6 | Light | Front:8 highlight patch lamp beads;
Rear:16 LED hard light source lamp beads. |
| 7 | Proof Pressure | 15-30MPa(Customized) |
| 8 | Focal Distance | Adjustable |
| 9 | Brightness Level | 5 levels adjustable |
