TLSW Series Wide Angle Camera Probe for Borehole Inspection Camera System

Quantity:

Product Description


Description
Made of stainless steel with excellent waterproof performance, high pressure resistance, high temperature resistance and high temperature resistance.

Various specifications of the underwater probe can be used with the monitor, 80mm, 50mm, 40mm three kinds of probes can be freely interchangeable according to the aperture (at the same time can be interchangeable with the temperature probe).

Built-in 6-9 LED probe with high quality, high power lamp, LED lamp has excellent characteristics that cold light and low light attenuation.

The cover of the probe is high transparent resin, not easy to broken, will not leak in water even descending up to 3000 meters.

With high water-proof ability, we could could customized the cable length as 50m,200,300,500....2000m, or even longer for water well or oil well.

TLSW Series Wide angle Camera Probe for Borehole Inspection Camera System-1

TLSW Series Wide angle Camera Probe for Borehole Inspection Camera System-2

Specifications
 Sn.  Item  Paramerter
1  Sensor  1/2 inch CCD,12 million pixels
2  Resolution  1200TVL
3  Signal system   PAL
4  Minimum illumination  0.001LUX/F1.2
5  White Balance Mode  AWB
6  Backlight compensation  HLC
7  Working voltage  DC12V±5%
8  Light  6-9 pieces of LED
9  Pressure proof  30MPa(equal to 3000 meter water pressure)
