TLSR-1 Camera Probe for Borehole Inspection Camera System

Quantity:

Product Description


Description

This Camera Probe is very small, particularly suitable for narrow well, equipped with Push Rod, could be used for narrow and extreme complex environment conditions.

Its material is stainless steel, it is strong and rust-proof, also, have high water pressure proof ability.

Front Lights design,enough for narrow well.

Rotatable capacity: LR(circle) and UD(Bend forward), you can adjust any inspection angle you want.

A brightness control:  can be adjusted by button on the main box front light source brightness, dimming level 5. It is very convenient and useful.


TLSR-1 Camera Probe for Borehole Inspection Camera System-1

TLSR-1 Camera Probe for Borehole Inspection Camera System-2


Specifications
 Sn.  Item  Paramerter
1  Probe Size  Î¦50 mm
2  Probe Material  Stainless steel
3  Camera Cover Material  Explosion-proof optical glass
4  Camera Pixels  CCD720 HD (better than CMOS camera, 1200 line)
5  Rotatable Angle  LR 360 °, UD 180 °
6  Light  8 highlight patch lamp beads;
7  Proof Pressure  15-30MPa(Customized)
8  Focal Distance  Adjustable
9  Brightness Level  5 levels adjustable
